CSM Φ2.0の丸型のPultrudedの技術を増強する非金属FRP/KFRP棒の本部
製品詳細
kfrp材料
,FRPのメンバー
非金属FRP/KFRP棒の中央強さメンバーCSM、KFRP棒Φ2.0
私達は繊維の光ケーブルのためのPultruded FRP棒の強さメンバーを提供する中国の非金属FRP棒の中央強さメンバーの製造業者/製造者です。
指定:（円形FRP:∮0.4-∮5.0）
| 特性 | 価値 |
| 引張強さ（Mpa） | ≥1100 |
| 抗張係数（Gpa） | ≥50 |
| Flexural強さ（Mpa） | ≥1100 |
| Flexural係数（Gpa） | ≥50 |
| 壊れ目（%）の延長 | ≤4 |
|
線形上昇温暖気流の係数
拡張（- 30-80℃） （1/℃） |
<8*10-6 |
| 直径の許容（mm） | ±2% |
| 最低の曲げ半径（mm） | 40*D |
| 密度（g/cm3） | 2.05-2.15 |
| 高温折り曲げ試験（50D、100℃、120h） |
bur無しのひび
壊れ目 |
| 低温の折り曲げ試験（50D、- 40℃、120h） |
bur無しのひび
壊れ目 |
| ねじり（±360°/m） | 崩壊させない |
We develop and produce Flat FRP strength member for different application.
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
Cable Strengthen Core For Fiber Optical Cables Non-Metallic FRP Rod Central Strength Member CSM Basic Info Technique: Pultrusion Type: Themosetting Plastic Profiles Diameter Ranges: 0.40 mm to 5.00 mm HS Code: 70199090 Materials: Resin, E-glass Fiberglass, Agents, etc. Applications: Central or peripheral strength member for fiber optical cables Origin: Jiangsu, China Product Description: Non-metallic FRP Rod strength member, usually located at the center or the periphery of
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
