軽量の繊維強化樹脂、KFRP Aramid繊維強化プラスチック繊維の光ケーブル サポート
製品詳細
FRP の棒
,frp の繊維強化プラスチック
繊維の光ケーブルのためのKFRP Aramidのメンバー
繊維の光ケーブルのためのKFRP Aramidのメンバー:
KFRPは光ファイバ ケーブルのためのメンバーを増強します:
1.Product指定:
Φ0.40mm Φ0.50mm ×Φ0.58mm
Φ0.45mm Φ0.62mm ×Φ0.68mm
2. 特徴:
1) 軽量および高力:KFRPに低密度の特徴がおよび高力はあります。強さのその比率および係数は鋼線およびGFRPのそれらより高いです;
2) 低い拡張:KFRPに温度の広い範囲で鋼線およびGFRPより低い熱膨張率があります;
3) 影響および壊れ目の抵抗:KFRPに大いにより高い引張強さ（≥1700Mpa）があります。それは壊れています、残された引張強さ1300Mpaであることができます;
4) よい柔軟性:KFRPは適用範囲が広く、曲がって容易です。その最低の曲がる直径はKFRPの棒の直径の24回です;
5) 屋内レイアウトのためによい審美的そして適用範囲が広い、特に。
3. KFRPの技術的なパフォーマンス インジケータ:
NO.ItemUnitIndex
1
直径
許容
Bodymm±0.05
コーティング
2Non-circularityBody%≤5.0
コーティング
3Minimum曲がる特性--
曲がる直径:10D、
bur、ひびおよび壊れ目無しの表面
4Tensile StrengthMpa≥1700
5Tensile ModulusGpa≥52
6高い-温度の折り曲げ試験（80℃、24h）--
曲がる直径:30D、
bur、ひびおよび壊れ目無しの表面
7Low温度の折り曲げ試験（- 40℃、24h）--bur、ひびおよび壊れ目無しの表面
Diameter 0.5mm-7.0mm Length 50km/drum. strength member Product Description:FRP Rod is a type of reinforced plastic product with high tensile strength and strong durability. It is made of high-strength composite material, which is composed of fiber and resin. The FRP Rod is available in different sizes, ranging from 0.5mm to 7.0mm in diameter, and in various shapes, including rod and flat. The length of each FRP rod is 50km/drum. The color of the FRP rod is clear. FRP rods can
Product Description: Fiber Reinforced Plastic Rods are ideal for a variety of applications due to their outstanding features. FRP rods are available in a range of colors, including clear, and lengths, from 50km/drum. The diameter of FRP rods range from 0.5mm to 7.0mm and can be shaped into rods or flats. Moreover, their tensile strength is high, making them the perfect choice for a variety of industrial and commercial applications. FRP sticks, also known as FRP poles, are an
Product Description: Fiber Reinforced Plastic Rod (FRP-Stick) is a high-performance stick-shaped rod made of fiber-reinforced plastic. It is an ideal material for many applications in various industries due to its excellent tensile strength and superior durability. The FRP-Stick-Rod is available in different shapes such as rod or flat, and can be custom manufactured to meet your specific requirements. The rod has a diameter ranging from 0.5mm to 7.0mm and length up to 50km
Product Description: Fiber Reinforced Plastic Rod, which is also known as Fiberglass Stick or FRP Rod, is a type of material that features a high tensile strength. It is made of fiber reinforced plastic and comes in rod or flat shapes with a diameter range from 0.5mm to 7.0mm. It is sold in a length of 50km/drum, which makes it an ideal material for many applications. Its high tensile strength makes it perfect for use in a wide range of industries, such as automotive,
