表面Frpの強さメンバーのプラスチック棒の繊維強化ガラス繊維は滑らかになる
製品詳細
滑らかなFrpの強さメンバーの表面
,プラスチック棒のガラス繊維のFrpの強さメンバー
,点のFrpの不均等なメンバー無し
繊維強化プラスチック棒のガラス繊維のFrpの強さメンバー
FRPは繊維光学のドロップ・ケーブルの強さそして耐久性を提供する共通の補強である。
FRPはガラス繊維の補強から成っている複合材料であり、ポリマー樹脂、FRPはまたガラス繊維補強ポリマーを意味できる。ガラス繊維は強さおよび剛さを提供し、樹脂は形を提供し、繊維を保護する
|
ガラス繊維はプラスチックを補強した
|
|||||||||
|
0.5
|
0.6
|
0.8
|
1
|
1.2
|
1.25
|
1.3
|
1.4
|
1.5
|
1.6
|
|
1.8
|
2
|
2.1
|
2.2
|
2.3
|
2.4
|
2.5
|
2.6
|
2.7
|
2.8
|
|
3
|
3.2
|
3.3
|
3.5
|
|
|
|
|
|
|
|
いいえ。
|
変数
|
単位
|
価値
|
|
1
|
直径の許容
|
mm
|
0.05
|
|
2
|
密度
|
g/cm3
|
2.05 - 2.15
|
|
3
|
出現
|
|
表面のひびか欠陥無し
|
|
4
|
引張強さ
|
MPa
|
≥1200
|
|
5
|
抗張係数
|
MPa
|
≥50
|
|
6
|
Flexural強さ
|
MPa
|
≥1200
|
|
7
|
Flexural係数
|
MPa
|
≥50
|
|
8
|
線形熱拡張の係数
|
1/℃ （- 30℃ | +80℃）
|
<8×10-6
|
|
9
|
壊れ目の延長
|
%
|
2.5 - 4.0
|
|
10
|
24 hrs後の吸水
|
%
|
≤0.1
|
|
11
|
最低の曲げ半径
|
mm （25℃）
|
25D
|
|
12
|
高温曲がる性能
|
50D、100℃、120h
|
分解か薄片分離無し
|
|
13
|
低温の曲がる性能
|
50D、-40℃、120h
|
分解か薄片分離無し
|
|
14
|
防水
|
80D、80℃
|
分解か薄片分離無し
|
続くことはFRPのメンバーの材料の1つである:
